AMOGH
SMART
OPHTHALMIC GREEN LASER SYSTEM-532 NM
Single Spot Technology
The Amogh Smart is the green laser photo coagulator system designed with precision to treat retinal disorders using a single spot technology. Its effective touch screen interface allows easy access to the entire system providing efficient treatment to the patients.
Efficient Workflow
The in-built user interface and the LCD touch screen display allows quick access to the treatment parameters providing extremely fast treatment with instant reports thus maximizing the workflow efficiently.
Solid-State Technology
The patented solid-state technology in Amogh Smart ensures stable laser output providing reliable therapeutic laser beam for treating retinal diseases.
Unique Joystick
Electronic micro manipulator on the joystick ensures the ultimate in controlled safety. The motorized joystick provides an ease of use to the surgeon allowing an increased level of comfort during treatment.
Maximum Focus
The precise guidance of the aiming beam and the therapy beam guarantees optimum illumination on the site of treatment at all times whether it is in the far periphery or in the vicinity of the macula.
Safety Filters
True color and permanently inbuilt safety filters enable comfortable physician’s view and eliminates color distortion.
Magnificent Operative Design
The Amogh Smart provides an additional advantage to the users by providing LED illumination in the fiber optic cable connecting port, foot pedal & ON/OFF switch for their easy identification in the dark room. It also has an integrated voice confirmation technology providing better guidance to the user.
Laser Indirect Ophthalmoscope (Optional Delivery System)
Amogh Smart is designed with LIO compatibility which is ideal for patients who are best examined and can be treated in supine position, including neonates, small children and disabled patients. The major advantage of this is it has a variable focus option which provides improved diagnosis.
Other features:
Vertical movement adjustment for illumination beam
Ultra view inbuilt eye safety laser filters provides a crystal clear view of developing lesions
Coaxial system of laser aiming beam along with white light illumination gives comfortable treatment
LIO can be made compatible for other selected lasers
True focus optical system
Small pupil adjustment
Endoprobes For Ophthalmic Endophotocoagulation (Optional Delivery System)
These disposable probes have prefect ergonomic design, straight & curved/angled tip which are pre-sterilized. It provides an easy entry through small gauge cannulas and its tapered curve provides excellent laser energy delivery.
Other features:
Available in 20G, 23G 25G & 27G series
Compatible for other selected laser photocoagulators
Reliable spot placement at far periphery
.png)
Footswitch
Compact and convenient foot switch
Technical Specification of green Laser Single Spot (GLS 532nm)
AMOGH SMART
Treatment laser
Diode pumped, Frequency doubled, True CW, Solid state
Laser module capacity
3 Watts
Aiming Beam
635nm,Semiconductor diode laser, 0 to 1mW (variable)
Power Adjustment
Variable from 10 to 1500 mW
Power Input
100-240V AC 50-60Hz, 2A
Cooling
Thermo electric cooling (Peltier) and Air cooled
Operation mode
Repeat Pulse, Single pulse & Continuous mode
Screen Display
LCD touch screen
Life time
10,000 Working hours
Dimensions
290mm (H) × 175mm (W) × 365mm (D)
Weight
8 Kgs (Without Packing)
Power consumption
100 Watts
Pulse Duration
10 ms - 10 Sec
Pulse Interval
10 ms - 10 Sec
Treatment laser safety
Class IV
Technical Specification of integrated Laser Slit Lamp (ILS)
Laser Spot Diameter
Adjustable spot size from 50 -1000µ
Eye Piece
12.5x
Magnification
6x, 10x, 16x, 25x, 40x
Standard Slit’s
0°, 45° & 135°
Illumination
12V-30W Halogen Lamp, Brightness Variable
Slit length Adjustment
Adjustable in step of 1, 3, 5, 8, 10 ,14mm
Slit Width Adjustment
Continuously adjustable from 0-14mm
Inter Pupillary Distance
55 – 75 mm
Micro Manipulator
Electronic micro manipulator in the Joystick
Working Distance
120 mm for using all types of laser contact Lenses
Power Input
100-240V AC 50-60Hz, 2.5A
Filters
Yellow, green (red free) & Cobalt Blue
Laser spot size display
7 Segment LED
Micro manipulation movement
360°
Power Consumption
65 Watts
Laser Beam Delivery
Coaxial Delivery With Slit Illumination
Movement Ranges :
Longitudinal (In /Out )
99 mm Lateral(Left / Right ) :118 mm
Vertical (Up /Down)
30 mm Chin Rest Range :90 mm
Dimensions
530 (L) x 380 (W) x 600 (H) mm
Weight
10 Kgs
Technical Specification of Laser Indirect Ophthalmoscope (LIO)
LIO Illumination
LED 1Watt
Output
3.3 V DC, 700mAh
Standard Spot Size
200µ on the retina
Standard working distance
350mm
Variable spot size (With working distance)
̴ 181µ (300mm) - ̴ 550µ (700mm) on the retina.
Laser Safety Filter
Ultra clear view and permanently fixed.
Illumination field
Clear circular
Optical system
Stereoscopic
Pupillary distance
55 to 75mm
Aperture size
4.0mm, 3.0mm, 1.2mm
Image size
80.0mm, 60.0mm & 25.0mm
Intensity control
Continuously variable
Standard Filters
Yellow , White & Cobalt Blue
Power consumption
2 Watts
Power input
100-240V AC, 50-60Hz, 2A
Weight
700 grams(approx)
Dimension
Standard packing foam bag 230x520x450mm
Power consumption
2 Watts
Power input
100-240V AC 50-60Hz, 2A
Weight
700 grams(approx)
Dimension
Standard packing foam bag 230x520x450mm
Accessories:
